Huepar P04CG Laser Level
Huepar P04CG Laser Level
Huepar P04CG Laser Level
Tax included, shipping calculated at checkout.
Select Option
Add Top Accessories
Huepar LR5RG Line Laser Receiver
Huepar TPD16 - 1.6m/5.2ft Flat Head Aluminum Tripod
Huepar LP36 - 12 Ft./3.7m Telescoping Pole
Buying Spare Batteries?
Expand Extended Warranty?
9 in stock
Couldn't load pickup availability
Pay with Ease
Trusted Delivery with DHL/UPS/FedEx/USPS
-
Ordered
- - -
Order Ready
- - -
Delivered
Huepar Care
By purchasing this one-year extended warranty, your Laser Level can enjoy a total of 3 years of warranty service.
1. This product (Huepar Care) is a special service product and cannot be returned.
2. Valid for one year starting from the date of purchase.
3. The service includes Free replacement of accessories such as laser windows, chargers, batteries, etc, and other accidental damage.
4. Restricted to huepar.com orders.
5. Huepar official has the final right to interpret this.
±1/9 inch at 33Ft
Horizontal/Vertical Accuracy: ±3MM/10M
Phone App &
Bluetooth control
Bluetooth connectivity enables you to control the 360 laser level around the room with Huepar App or remote control.
Rechargeable Li-ion Battery
10.8V / 2600mAh Li-Ion battery with Type-C connector provides up to 7 hours of running time.
Self-leveling Range ±3° & Manual mode
The laser tool self-levels and indicates out-of-level when unlocked. When the pendulum is locked, the laser tool can be used at any angle.
High Protection Grade
The durable, high-quality shockproof enclosure provides 4 ft. collision protection. It's compact and lightweight for easy gripping, yet large enough to sit stably, making it ideal for construction site work.
4x360°
Osram Green Beam
P04CG Professional 4x360° Green Laser Lines: 2 horizontal and 2 vertical 360° planes. Top horizontal for ceiling installation, floor horizontal for tiling or leveling, and vertical lines for wall leveling.
Huepar App
Phone & Bluetooth Control
Bluetooth connectivity allows control of the 360 laser level with the Huepar App or remote control to switch laser lines, pulse mode, and select laser planes.
10 hours running time
Large Capacity Li-Ion Battery
Laser Level with 10.8V / 2600mAh Li-ion battery providing 10 hours runtime. Quick-release, easy to use, and charge separately with four power indicators for charging status.
Pulse Mode
Self Leveling Mode
Self-levels within 4°, or switch to manual mode for any angle. Offers a 40m/130ft range with ±3mm at 10m accuracy. Outdoor pulse mode with Huepar receiver extends range to 60m/200ft.
1/4"-20
Metal Laser Window
Over-molded metal laser window with IP54 resistance, replaceable with a screwdriver.
Comes with a hard carry case for easy transport and storage.
In the Box
Specifications
Laser Info
Osram Green Beam
4 x 360° 16 Line Laser Levels
Wavelength 510-530nm
Class 2 (IEC/EN60825-1/2014)
Laser Accuracy
±3mm/10m
(±1/9 in. at 33 ft)
Leveling Range / Time
±3°
3 seconds
Working Range
Max Working Distance
20m/66ft
40m/130ft with Pulse Mode
Minimum Distance From The Ground
10mm
Minimum Distance From The Wall
13mm
Power System
Li-ion Battery 11.1V 2600mAh
Working Time 7 hrs
Charging Time 4 hrs
TYPE-C Charing Port
Durable Design
Working Temperature
-10℃ ~ 50℃ (14℉ ~ 122℉)
Storage Temperature
-20℃ ~ 70℃ (-4℉ ~ 158℉)
Main Material
ABS + Metal
IP Rating
IP54
Dimensions
Model Weight
930g (2.05 pounds)
Model Size
137 x 96 x 147mm
Item Weight
1.71kg (3.76 pounds)
Package Dimensions
37 x 30.8 x 13.6cm
(14.57 x 12.13 x 5.35 inches)
Suitable Accessories
Mount Size
1/4''-20
Laser Detector
LR5RG/LR6RG/LR8RG
Tripod
LP36/TPD05/TPD14/TPD16
Base Adapter
AT2/PV3/PV11+/PV15
Packing List
1 x Huepar P04CG
1 x Bluetooth Remote Control
1 x Rechargeable Li-ion Battery
1 x Power Adapter
1 x Type-C cord
1 x Magnetic Bracket
1 x Steel Sheet
1 x Laser Target Plate
1 x Hard Carry Case
1 x User Manual
Find your perfect laser level
| Product Info | |||||
|---|---|---|---|---|---|
Product SKU |
P04CG
|
S04CG-L
|
S04CG
|
704CG
|
LS04CG
|
Product type |
4D Laser Levels
|
4D Laser Levels
|
4D Laser Levels
|
4D Laser Levels
|
4D Laser Levels
|
| Featured | |||||
Number of Lines |
|
|
|
|
|
Laser Lines |
|
|
|
|
|
Laser Beam Supplier |
|
|
|
|
|
Laser Beam Color |
|
|
|
|
|
Laser Wavelength |
|
|
|
|
|
Line Accuracy |
|
|
|
|
|
Leveling / Compensation Range |
|
|
|
|
|
Max Self-leveling Time (Seconds) |
|
|
|
|
|
Extra features |
—
|
—
|
|
—
|
—
|
Bluetooth Connectivity |
|
|
|
|
|
Remote Control |
|
|
|
|
|
Dot Accuracy |
|
|
|
|
|
Line Switching |
|
|
|
|
|
Pulse Laser Receiver Mode |
|
|
|
|
|
Working Range (60-100 LUX) |
|
|
|
|
|
Working Range with Detector |
|
|
|
|
|
AA Battery |
|
|
|
|
|
Li-ion Battery |
|
|
|
|
|
Working Time (Hours) |
|
|
|
|
|
Charging Time (Hours) |
|
|
|
|
|
Mount Size |
|
|
|
|
|
Durable Design |
|
|
|
|
|
Hard Carry Case |
|
|
|
|
|
FAQ
Can you tell me which laser level has a longer working range with the S04CG or P04CG receiver?
Can you tell me which laser level has a longer working range with the S04CG or P04CG receiver?
Can you tell me what he differences between the P04CG and S04CG?
Can you tell me what he differences between the P04CG and S04CG?
Can laser level be used outdoors?
Can laser level be used outdoors?
Why is the laser level display wrong/ display angles?
Why is the laser level display wrong/ display angles?
Why does the machine's laser line keep flashing and sounding an alarm?
Why does the machine's laser line keep flashing and sounding an alarm?
What's the warranty?
What's the warranty?
Endorsed By
≥ 5,000 times Button test
All buttons are tested to ensure proper functionality.
≥ 5,000 times Switch test
The switch is tested repeatedly to ensure that the machine works stably.
≥ 1,000 times Charging test
Make sure the charging interface is working properly and not loose.
≥ 500 hours Working test
Laser tube aging test to ensure no brightness attenuation.
IP54 extreme environment test
Waterproof and dustproof, ensuring normal use in dusty environments.
Natural drop and shock test
Simulate natural drops while maintaining accuracy.
Simulated transportation
Simulate complex transportation environments to ensure unchanged accuracy.
High and low temperature test
Make sure the device can work normally between -10℃ ~ 50℃
High Quality Ensured by Professional Testing
Every product goes through 8 strict inspection processes before it is delivered to you to ensure that you receive products of consistent quality.
